Description
STAFFORD MULTIPRO 200 WELDER
MULTIPRO 200 – The Ultimate 4-in-1 Welding & Cutting Solution
The MULTIPRO 200 is a powerful, professional-grade machine designed for both the worksite and the workshop. Built for versatility and reliability, it delivers outstanding performance across multiple processes.
- Quick & Easy Setup – Synergic MIG programs make getting started effortless.
- 4-in-1 Multi-Process Power – MIG, Stick (MMA), DC TIG, and Plasma Cutting in one machine.
- Smooth Wire Feeding – Precision geared wire drive system ensures consistent results.
The MULTIPRO 200 is the all-in-one solution for professionals who demand performance, efficiency, and reliability.
In the box:- MULTIPRO 200 Welder
- 4m MB24 MIG Torch
- 4m WP26 TIG Torch
- 4m PT31 Plasma Torch
- 3m Twist Lock Electrode Holder
- 3m 300A Earth Clamp & Lead
- 1.8m Quick-Connect Gas Hose
- Operating Manual
- 0.8-0.9mm V Groove Roller
- 0.8-0.9mm F Groove Roller
- 0.8-1.0mm U Groove Roller
- 4m Teflon Liner
Machine Specifications
Primary Input Voltage
240V Single-Phase
Supply Plug
15A
Protection Class
IP21S
Standard
AS 60974.1
Minimum Generator (kVA)
10.0
Dinse Connector
35/50
Warranty
2 Years
Weight (kg)
15
Suitable Materials
MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
MMA: Mild Steel, Stainless Steel, Cast Iron
TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze
MIG Specifications
MIG Current Range
30-200A
MIG Duty Cycle @ 40°C
20% @ 200A
60% @ 115A
100% @ 90A
MIG Wire Sizes
0.6-1.2mm
MIG Wire Spool Sizes
1kg & 5kg
MIG Welding Thickness Range
1-10mm
Drive Roller Size
30/22
MMA Specifications
MMA Current Range
20-200A
MMA Duty Cycle @ 40°C
20% @ 200A
60% @ 115A
100% @ 90A
MMA Electrode Range
2.5-4.0mm
MMA Welding Thickness Range
2-12mm
TIG Specifications
TIG Ignition Type
DC Lift Arc
TIG Current Range
5-200A
TIG Duty Cycle @ 40°C
20% @ 200A
60% @ 115A
100% @ 90A
TIG Welding Thickness Range
1-8mm
Plasma Specifications
Plasma Cut Current Range
20-40A
Plasma Cut Duty Cycle @ 40°C
20% @ 40A
60% @ 23A
100% @20A
Air Flow Pressure
70-87 psi
5-6 bar
0.5-0.6 MPa
Mild Steel Cut Thickness
10mm
Mild Steel Severance Thickness
14mm
Stainless Steel Cut Thickness
6mm
Stainless Steel Severance Thickness
8mm
Aluminium Cut Thickness
6mm
Aluminium Severance Thickness
8mm
