Description
RAZOR ARC 140 Welder
Perfect for the work site or the home garage, this powerful STICK machine comes in the most portable case.
- Packed full of advanced features including hot start, arc force and anti-stick
- Capable of DC Lift Arc TIG for more versatility
- A 5-year warranty to reflect our confidence in this machine
SKU: U13004
In the box
- RAZOR ARC 140 Welder
- 4m Twist Lock Electrode Holder
- 4m 300A Earth Clamp & Lead
- Operating Manual
Machine Specifications:
Primary Input Voltage
240V Single-Phase
Supply Plug
10A
Ieff (A)
9.7
Imax (A)
27.0
Open Circuit Voltage (OCV)
78.0
Open Circuit Voltage with VRD Active (V)
11.0
Protection Class
IP23S
Insulation Class
H
Minimum Generator (kVA)
8.0
Dinse Connector
35/50
Standard
AS 60974.1
Warranty
5 Years
Weight (kg)
5.5
Dimensions (LxWxH)
370 x 125 x 255mm
Suitable Materials
MMA: Mild Steel, Stainless Steel, Cast Iron
TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze
MMA Specifications
MMA Current Range
20-140A
MMA Duty Cycle @ 40°C
15% @ 140A
60% @ 70A
100% @ 54A
MMA Electrode Range
2.5-3.2mm
MMA Welding Thickness Range
2-8mm
TIG Specifications
TIG Ignition Type
DC Lift Arc
TIG Current Range
10-140A
TIG Duty Cycle @ 40°C
20% @ 140A
60% @ 80.8A
100% @ 62.6A
TIG Welding Thickness Range
1-5mm
